DESCRIPTION
The X25020 is a CMOS 2048-bit serial E2PROM, internally organized as 256 x 8. The X25020 features a serial interfacex250 and software protocol allowing operation on a simple three-wire bus. The bus
signals are a clock input (SCK) plus separate data in (SI) and data out (SO) lines. Access to the device is controlled through a chip select (CS) input, allowing any number of devices to share the same bus.
FEATURES
? 1MHz Clock Rate
? SPI Modes (0,0 & 1,1)
? 256 X 8 Bits
—4 Byte Page Mode
? Low Power CMOS
—10μA Standby Current
—3mA Active Write Current
? 2.7V To 5.5V Power Supply
? Block Lock Protection x250
—Protect 1/4, 1/2 or all of E2PROM Array
? Built-in Inadvertent Write Protection
—Power-Up/Power-Down protection circuitry
—Write Latch
—Write Protect Pin
? Self-Timed Write Cycle
—5ms Write Cycle Time (Typical)
? High Reliability
—Endurance: 100,000 cycles per byte
—Data Retention: 100 Years
—ESD protection: 2000V on all pins
? 8-Lead PDlP Package
? 8-Lead SOIC Package
